UEA CRAM Lab O2 and CO2 calibration results
RUN = 200922b
PROCESSED: 17:34:15 Mon 21Aug2023

Notes
Logfile

Results

Using data from 267.04 to 267.35 (Day of Year and Day Fraction)
(Position, CylinderID, SIO_CO2, SIO_CO2_sigma, SIO_CO2_slope, GMD_CO2, GMD_CO2_sigma, GMD_CO2_slope, CO2_n, d(O2/N2), d(O2/N2)_sigma, d(O2/N2)_slope, d(O2/N2)_n)

2 D548325 411.749 0.003 -0.021 411.941 0.003 -0.021 5 -626.37 1.95 -15.27 5
5 D753898 371.713 0.058 0.026 371.917 0.058 0.026 5 -423.29 0.83 2.91 5
9 D753902 598.529 6.586 -2.742 604.121 6.591 -2.775 5 -1446.43 6.90 -24.10 5
10 D753899 714.050 16.806 0.959 730.171 16.823 0.925 5 -1768.06 14.67 -41.14 4
11 D548332 475.882 0.312 0.001 476.402 0.313 0.000 5 -942.00 1.22 -5.05 5
13 D089506 402.721 0.007 0.022 402.925 0.006 0.022 5 -591.23 1.38 4.92 4
15 D548331 409.853 0.006 0.048 410.047 0.006 0.048 5 -703.28 1.54 9.95 5
WT D258968 406.305 0.006 -0.003 406.503 0.006 -0.002 60 -844.25 0.56 3.80 60
Text File

Raw Data and Diagnostics Figures

CO2 Timeseries
 CO2 Averages for Unknowns
 CO2 Averages for Knowns
Jog Ave. Diagnostics 1
 Jog Ave. Diagnostics 2
 Jog Std. Dev. Diagnostics
Jog Slope Diagnostics
 Rollover Effect
 Flushing Effect
CO2 Parameters
 CO2 Results
 O2 Timeseries
O2 Averages for Unknowns
 O2 Averages for Knowns
 O2 Parameters
O2 Results
 Residuals

Reference Cylinders, Assigned Concentrations, and Calculated Offsets from Fit

(Position, Cylinder ID, SIO CO2 in ppm, SIO Delta-CO2, SIO CO2 sigma, GMD CO2 in ppm, GMD Delta-CO2, GMD CO2 sigma, CO2 n, d(O2/N2) in per meg, Delta-d(O2/N2), d(O2/N2) sigma, d(O2/N2) n, Plots)

3 D089507 428.087 -0.006 0.005 428.275 -0.008 0.005 5 -559.23 -0.37 1.55 5    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2    CO2 Fits 3   O2 Fits 3
4 D801299 381.475 0.001 0.001 381.695 0.001 0.001 5 -477.75 -0.92 0.54 5    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2
7 D073409 398.707 -0.005 0.004 398.918 -0.007 0.004 5 -651.78 0.92 1.05 5    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2
8 D073419 440.065 0.002 0.001 440.275 0.003 0.001 5 -919.32 -1.73 0.55 5    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2
12 D073418 413.092 0.008 0.010 413.280 0.010 0.010 5 -779.40 2.29 0.78 4    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2

Measured Cylinders and Calculated Concentrations

(Position, Cylinder ID, Plots)
(Day of Year and Day Fraction, SIO CO2 in ppm, SD CO2 (ppm), d(O2/N2) in per meg, SD d(O2/N2) (per meg), GMD CO2 in ppm, SD CO2 (ppm), Plots)

2 D548325    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
266.979 411.760 0.012 -628.81 1.93 411.951 0.012
267.099 411.749 0.010 -625.33 3.36 411.940 0.010
267.104 411.753 0.013 -623.47 2.38 411.944 0.013
267.224 411.751 0.011 -628.15 2.10 411.942 0.011
267.229 411.750 0.013 -627.14 2.19 411.942 0.013
267.349 411.745 0.010 -627.77 2.07 411.936 0.010
267.354 411.748 0.011 -625.31 1.70 411.939 0.011
267.474 411.763 0.008 -627.86 1.76 411.955 0.008

5 D753898    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
266.995 371.615 0.010 -425.09 2.57 371.819 0.010
267.083 371.765 0.015 -424.69 2.32 371.969 0.015
267.120 371.664 0.010 -422.56 2.68 371.868 0.010
267.208 371.738 0.012 -422.78 2.38 371.942 0.012
267.245 371.639 0.014 -423.16 2.61 371.842 0.014
267.333 371.760 0.009 -423.28 2.02 371.964 0.009
267.370 371.744 0.015 -422.39 1.96 371.948 0.015
267.459 371.798 0.012 -421.94 2.69 372.002 0.012

9 D753902    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
267.010 609.484 0.023 -1428.74 2.29 615.086 0.023
267.068 593.990 0.000 -1445.76 2.38 599.582 0.000
267.135 606.250 0.032 -1438.76 2.37 611.851 0.032
267.193 594.153 0.055 -1454.02 2.40 599.743 0.055
267.260 605.185 0.000 -1440.74 2.63 610.778 0.000
267.318 593.066 0.000 -1452.87 2.44 598.651 0.000
267.385 595.844 0.059 -1451.90 2.41 601.468 0.059
267.443 586.270 0.000 -1461.52 2.90 591.849 0.000

10 D753899    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
267.016 742.742 0.000 -1725.50 2.45 758.909 0.000
267.062 702.760 0.000 -1764.63 2.32 718.871 0.000
267.141 733.749 0.030 -1748.71 3.05 749.898 0.030
267.187 702.880 0.000 -1779.99 2.52 718.991 0.000
267.266 731.013 0.016 -1753.16 11.39 747.143 0.016
267.312 699.847 0.047 -1778.90 2.54 715.953 0.047
267.391 699.827 0.000 -1785.67 2.12 716.027 0.000
267.438 681.042 0.040 -1801.76 3.09 697.141 0.040

11 D548332    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
267.021 476.422 0.014 -941.74 2.38 476.944 0.014
267.057 475.684 0.012 -940.02 2.71 476.205 0.012
267.146 476.271 0.016 -943.13 2.73 476.793 0.016
267.182 475.690 0.013 -942.79 1.92 476.210 0.013
267.271 476.166 0.014 -942.33 3.97 476.687 0.014
267.307 475.597 0.015 -941.73 2.58 476.117 0.015
267.396 475.618 0.014 -943.99 2.46 476.140 0.014
267.432 475.440 0.018 -942.19 2.19 475.961 0.018

13 D089506    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
267.031 402.725 0.012 -594.18 2.44 402.929 0.012
267.047 402.721 0.016 -593.10 2.15 402.925 0.016
267.156 402.717 0.012 -591.27 1.78 402.921 0.012
267.172 402.716 0.010 -589.84 2.54 402.920 0.010
267.281 402.732 0.011 -592.27 5.38 402.936 0.011
267.297 402.718 0.013 -590.72 2.43 402.922 0.013
267.406 402.640 0.014 -592.00 2.35 402.844 0.014
267.422 402.606 0.040 -589.09 1.90 402.810 0.040

15 D548331    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
267.036 409.844 0.014 -705.48 1.89 410.038 0.014
267.042 409.846 0.014 -705.96 1.89 410.040 0.014
267.161 409.858 0.010 -702.13 1.90 410.052 0.010
267.167 409.848 0.010 -702.53 1.84 410.042 0.010
267.286 409.856 0.011 -703.10 1.92 410.050 0.011
267.292 409.860 0.016 -702.66 1.85 410.054 0.016
267.411 409.779 0.016 -702.37 2.46 409.973 0.016
267.417 409.750 0.012 -702.11 2.39 409.944 0.012
