UEA CRAM Lab O2 and CO2 calibration results
RUN = 180912a
PROCESSED: 16:56:11 Mon 21Aug2023

Notes
Logfile

Results

Using data from 255.86 to 256.45 (Day of Year and Day Fraction)
(Position, CylinderID, SIO_CO2, SIO_CO2_sigma, SIO_CO2_slope, GMD_CO2, GMD_CO2_sigma, GMD_CO2_slope, CO2_n, d(O2/N2), d(O2/N2)_sigma, d(O2/N2)_slope, d(O2/N2)_n)

2 D88532 382.130 0.008 -0.012 382.351 0.008 -0.012 8 -481.89 1.24 4.82 8
5 CC203963 409.989 0.007 -0.003 410.182 0.007 -0.003 8 -569.53 1.09 -0.37 8
6 D570040 405.331 0.007 -0.019 405.531 0.007 -0.019 8 -701.68 0.86 -1.29 8
9 D570039 412.135 0.009 -0.037 412.326 0.009 -0.037 8 -723.28 0.40 -1.24 8
10 D570036 418.182 0.017 -0.023 418.368 0.017 -0.023 8 -719.34 1.35 -3.42 8
11 D570038 462.761 0.042 -0.130 463.114 0.042 -0.129 8 -885.93 0.71 -1.85 8
13 D570035 399.014 0.010 -0.055 399.223 0.010 -0.055 8 -614.47 0.90 -1.46 8
14 D273559 374.991 0.017 0.061 375.204 0.017 0.061 8 423.20 1.59 -6.33 8
15 D570037 440.225 0.013 0.017 440.436 0.013 0.017 8 -802.47 0.66 -3.07 8
WT D258964 397.184 0.014 -0.078 397.396 0.014 -0.078 113 -752.58 1.22 4.96 113
Text File

Raw Data and Diagnostics Figures

CO2 Timeseries
 CO2 Averages for Unknowns
 CO2 Averages for Knowns
Jog Ave. Diagnostics 1
 Jog Ave. Diagnostics 2
 Jog Std. Dev. Diagnostics
Jog Slope Diagnostics
 Rollover Effect
 Flushing Effect
CO2 Parameters
 CO2 Results
 O2 Timeseries
O2 Averages for Unknowns
 O2 Averages for Knowns
 O2 Parameters
O2 Results
 Residuals

Reference Cylinders, Assigned Concentrations, and Calculated Offsets from Fit

(Position, Cylinder ID, SIO CO2 in ppm, SIO Delta-CO2, SIO CO2 sigma, GMD CO2 in ppm, GMD Delta-CO2, GMD CO2 sigma, CO2 n, d(O2/N2) in per meg, Delta-d(O2/N2), d(O2/N2) sigma, d(O2/N2) n, Plots)

3 D089507 428.087 -0.021 0.011 428.275 -0.023 0.011 9 -559.23 2.46 0.72 8    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2    CO2 Fits 3   O2 Fits 3
4 D801299 381.475 0.003 0.001 381.695 0.003 0.001 8 -477.75 -1.90 0.36 8    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2
7 D073409 398.707 -0.014 0.004 398.918 -0.015 0.004 8 -651.78 -0.49 0.86 8    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2
8 D073419 440.065 0.006 0.002 440.275 0.006 0.002 8 -919.32 -1.06 0.61 8    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2
12 D073418 413.092 0.023 0.006 413.280 0.025 0.006 8 -779.40 0.99 1.03 8    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2

Measured Cylinders and Calculated Concentrations

(Position, Cylinder ID, Plots)
(Day of Year and Day Fraction, SIO CO2 in ppm, SD CO2 (ppm), d(O2/N2) in per meg, SD d(O2/N2) (per meg), GMD CO2 in ppm, SD CO2 (ppm), Plots)

2 D88532    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
255.870 382.133 0.015 -484.45 2.31 382.354 0.015
256.011 382.141 0.012 -482.34 1.98 382.362 0.012
256.016 382.131 0.015 -482.30 2.08 382.352 0.015
256.157 382.131 0.011 -481.40 2.45 382.351 0.011
256.162 382.124 0.016 -480.52 2.11 382.345 0.016
256.303 382.123 0.012 -480.91 2.02 382.343 0.012
256.308 382.119 0.011 -482.11 2.34 382.340 0.011
256.448 382.138 0.015 -481.06 2.34 382.359 0.015

5 CC203963    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
255.886 409.976 0.012 -567.86 2.31 410.170 0.012
255.995 409.998 0.011 -570.79 2.13 410.192 0.011
256.032 409.993 0.014 -570.47 2.19 410.187 0.014
256.141 409.995 0.008 -568.31 2.44 410.189 0.008
256.178 409.992 0.009 -570.65 2.01 410.186 0.009
256.287 409.985 0.009 -569.09 1.92 410.179 0.009
256.323 409.983 0.013 -569.81 2.07 410.177 0.013
256.433 409.987 0.011 -569.26 2.08 410.180 0.011

6 D570040    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
255.891 405.325 0.012 -700.19 2.01 405.525 0.012
255.990 405.338 0.013 -702.64 2.11 405.538 0.013
256.037 405.341 0.012 -701.83 2.34 405.541 0.012
256.136 405.332 0.015 -702.38 2.28 405.532 0.015
256.183 405.332 0.009 -700.79 2.48 405.533 0.009
256.282 405.330 0.012 -702.20 2.51 405.530 0.012
256.329 405.323 0.013 -701.26 1.97 405.523 0.013
256.428 405.323 0.008 -702.16 2.75 405.523 0.008

9 D570039    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
255.907 412.137 0.011 -722.37 2.94 412.328 0.011
255.974 412.143 0.011 -723.30 2.33 412.334 0.011
256.053 412.141 0.011 -723.35 2.24 412.332 0.011
256.120 412.138 0.011 -723.56 2.56 412.329 0.011
256.198 412.146 0.013 -723.24 1.85 412.338 0.013
256.266 412.129 0.011 -723.73 2.11 412.321 0.011
256.344 412.126 0.017 -723.38 1.88 412.317 0.017
256.412 412.121 0.011 -723.30 2.49 412.312 0.011

10 D570036    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
255.912 418.167 0.010 -716.88 2.61 418.353 0.010
255.969 418.208 0.012 -718.73 2.16 418.394 0.012
256.058 418.172 0.011 -720.44 2.38 418.358 0.011
256.115 418.202 0.013 -719.40 2.19 418.387 0.013
256.204 418.178 0.017 -720.93 2.37 418.364 0.017
256.261 418.191 0.012 -718.83 2.21 418.376 0.012
256.349 418.158 0.016 -720.72 2.55 418.343 0.016
256.407 418.182 0.012 -718.76 2.14 418.368 0.012

11 D570038    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
255.917 462.837 0.015 -885.51 2.15 463.190 0.015
255.964 462.730 0.019 -885.86 2.10 463.083 0.019
256.063 462.814 0.017 -885.29 2.50 463.167 0.017
256.110 462.730 0.014 -885.45 2.22 463.084 0.014
256.209 462.757 0.013 -887.00 1.86 463.110 0.013
256.256 462.750 0.011 -885.43 2.58 463.104 0.011
256.355 462.725 0.015 -887.07 1.87 463.079 0.015
256.401 462.744 0.017 -885.82 1.80 463.098 0.017

13 D570035    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
255.928 399.030 0.011 -614.41 2.21 399.239 0.011
255.954 399.025 0.010 -613.82 2.14 399.234 0.010
256.073 399.015 0.015 -615.41 1.85 399.224 0.015
256.099 399.018 0.011 -613.39 2.42 399.227 0.011
256.219 399.012 0.010 -615.06 2.52 399.221 0.010
256.245 399.004 0.011 -613.57 2.24 399.214 0.011
256.365 399.003 0.010 -615.88 2.16 399.212 0.010
256.391 399.004 0.010 -614.19 2.17 399.214 0.010

14 D273559    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
255.933 374.990 0.009 425.72 2.19 375.203 0.009
255.948 374.985 0.009 425.11 2.36 375.198 0.009
256.079 374.969 0.012 421.16 2.41 375.181 0.012
256.094 374.987 0.010 423.81 2.43 375.199 0.010
256.224 374.974 0.010 422.16 2.71 375.187 0.010
256.240 374.992 0.013 423.25 2.46 375.205 0.013
256.370 375.016 0.013 422.31 2.18 375.229 0.013
256.386 375.014 0.010 422.11 2.40 375.227 0.010

15 D570037    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
255.938 440.201 0.014 -801.80 2.22 440.412 0.014
255.943 440.230 0.014 -802.36 1.97 440.441 0.014
256.084 440.220 0.011 -801.81 1.78 440.431 0.011
256.089 440.238 0.012 -801.60 1.99 440.449 0.012
256.230 440.218 0.014 -802.97 2.71 440.430 0.014
256.235 440.245 0.010 -802.94 2.43 440.456 0.010
256.375 440.223 0.012 -803.19 2.08 440.434 0.012
256.381 440.222 0.015 -803.11 2.17 440.433 0.015
