UEA CRAM Lab O2 and CO2 calibration results
RUN = 180115a
PROCESSED: 16:43:55 Mon 21Aug2023

Notes
Logfile

Results

Using data from 15.521 to 15.994 (Day of Year and Day Fraction)
(Position, CylinderID, SIO_CO2, SIO_CO2_sigma, SIO_CO2_slope, GMD_CO2, GMD_CO2_sigma, GMD_CO2_slope, CO2_n, d(O2/N2), d(O2/N2)_sigma, d(O2/N2)_slope, d(O2/N2)_n)

2 D88471 380.220 0.010 0.059 380.439 0.010 0.060 7 -419.89 2.08 -12.08 7
4 D88534 416.302 0.006 -0.026 416.489 0.006 -0.026 7 -745.18 1.27 -7.02 7
6 D88474 409.351 0.009 -0.032 409.546 0.009 -0.032 7 -535.31 1.55 -5.97 7
7 D596277 398.247 0.004 -0.001 398.457 0.004 -0.001 7 -750.75 1.41 -8.31 7
8 D88535 439.213 0.011 0.028 439.421 0.011 0.028 7 -510.53 1.64 -10.00 7
10 D548337 340.881 0.227 -0.469 340.853 0.227 -0.469 7 -165.87 1.58 2.65 7
11 D88536 397.208 0.010 0.030 397.420 0.009 0.030 7 -604.45 1.59 -10.32 7
14 D842554 397.679 0.007 0.022 397.890 0.007 0.022 7 -904.57 2.52 -6.33 7
WT D258964 397.452 0.006 -0.020 397.664 0.006 -0.020 91 -747.74 1.03 -7.11 91
Text File

Raw Data and Diagnostics Figures

CO2 Timeseries
 CO2 Averages for Unknowns
 CO2 Averages for Knowns
Jog Ave. Diagnostics 1
 Jog Ave. Diagnostics 2
 Jog Std. Dev. Diagnostics
Jog Slope Diagnostics
 Rollover Effect
 Flushing Effect
CO2 Parameters
 CO2 Results
 O2 Timeseries
O2 Averages for Unknowns
 O2 Averages for Knowns
 O2 Parameters
O2 Results
 Residuals

Reference Cylinders, Assigned Concentrations, and Calculated Offsets from Fit

(Position, Cylinder ID, SIO CO2 in ppm, SIO Delta-CO2, SIO CO2 sigma, GMD CO2 in ppm, GMD Delta-CO2, GMD CO2 sigma, CO2 n, d(O2/N2) in per meg, Delta-d(O2/N2), d(O2/N2) sigma, d(O2/N2) n, Plots)

3 D073409 398.707 -0.005 0.002 398.918 -0.006 0.002 7 -651.78 2.96 1.08 7    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2    CO2 Fits 3   O2 Fits 3
5 D089507 428.087 -0.006 0.003 428.275 -0.008 0.003 7 -559.23 1.09 0.88 7    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2
9 D073419 440.065 0.002 0.001 440.275 0.003 0.001 7 -919.32 -0.97 0.39 7    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2
12 D073418 413.092 0.011 0.005 413.280 0.013 0.005 7 -779.40 -0.64 1.27 7    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2
13 D801299 381.475 0.001 0.001 381.695 0.002 0.001 7 -477.75 -2.57 0.71 7    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2

Measured Cylinders and Calculated Concentrations

(Position, Cylinder ID, Plots)
(Day of Year and Day Fraction, SIO CO2 in ppm, SD CO2 (ppm), d(O2/N2) in per meg, SD d(O2/N2) (per meg), GMD CO2 in ppm, SD CO2 (ppm), Plots)

2 D88471    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
15.456 380.306 0.008 -408.37 2.05 380.525 0.008
15.586 380.201 0.012 -418.04 2.17 380.421 0.012
15.591 380.216 0.014 -416.25 2.32 380.435 0.014
15.721 380.217 0.011 -420.79 1.85 380.436 0.011
15.727 380.223 0.011 -420.10 2.47 380.443 0.011
15.857 380.223 0.010 -421.59 2.14 380.442 0.010
15.862 380.225 0.011 -420.25 2.11 380.445 0.011
15.992 380.234 0.014 -422.20 2.15 380.453 0.014

4 D88534    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
15.466 416.273 0.016 -741.51 1.88 416.460 0.016
15.576 416.304 0.012 -744.13 2.05 416.491 0.012
15.602 416.311 0.012 -743.30 1.92 416.498 0.012
15.711 416.303 0.017 -745.30 2.37 416.490 0.017
15.737 416.296 0.014 -744.54 1.99 416.483 0.014
15.846 416.303 0.012 -746.45 2.13 416.490 0.012
15.872 416.305 0.012 -746.80 2.16 416.492 0.012
15.982 416.292 0.016 -745.76 2.09 416.479 0.016

6 D88474    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
15.477 409.335 0.010 -534.85 1.57 409.530 0.010
15.565 409.358 0.012 -532.37 2.83 409.552 0.012
15.612 409.365 0.013 -534.57 2.07 409.559 0.013
15.701 409.351 0.009 -535.78 2.01 409.545 0.009
15.747 409.338 0.014 -537.38 1.84 409.532 0.014
15.836 409.344 0.013 -535.56 2.06 409.539 0.013
15.883 409.353 0.011 -536.10 2.06 409.548 0.011
15.971 409.348 0.017 -535.43 2.18 409.543 0.017

7 D596277    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
15.482 398.243 0.008 -743.74 2.11 398.454 0.008
15.560 398.246 0.013 -749.00 1.97 398.456 0.013
15.617 398.250 0.013 -748.80 2.06 398.460 0.013
15.695 398.240 0.014 -750.30 1.96 398.450 0.014
15.753 398.249 0.014 -751.52 2.03 398.460 0.014
15.831 398.249 0.014 -752.41 2.27 398.460 0.014
15.888 398.249 0.014 -751.54 2.04 398.459 0.014
15.966 398.243 0.010 -751.71 2.07 398.454 0.010

8 D88535    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
15.487 439.180 0.014 -504.56 2.19 439.387 0.014
15.555 439.217 0.012 -507.64 2.07 439.425 0.012
15.622 439.203 0.017 -509.07 2.52 439.411 0.017
15.690 439.211 0.011 -510.42 2.18 439.419 0.011
15.758 439.194 0.016 -511.59 1.71 439.402 0.016
15.826 439.229 0.014 -511.67 2.43 439.437 0.014
15.893 439.218 0.013 -511.06 2.39 439.426 0.013
15.961 439.219 0.011 -512.23 2.02 439.426 0.011

10 D548337    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
15.497 341.211 0.009 -158.94 2.36 341.183 0.009
15.544 340.781 0.012 -164.74 3.12 340.752 0.012
15.633 341.238 0.014 -168.30 2.80 341.210 0.014
15.680 341.111 0.013 -165.06 2.26 341.083 0.013
15.768 340.652 0.010 -167.95 2.46 340.624 0.010
15.815 340.628 0.010 -165.04 2.12 340.600 0.010
15.904 340.918 0.011 -165.52 2.03 340.891 0.011
15.951 340.840 0.013 -164.49 2.80 340.812 0.013

11 D88536    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
15.503 397.207 0.014 -598.40 1.93 397.419 0.014
15.539 397.210 0.010 -602.08 1.73 397.422 0.010
15.638 397.189 0.013 -602.86 1.92 397.401 0.013
15.674 397.210 0.010 -604.11 2.33 397.422 0.010
15.773 397.207 0.013 -604.47 1.84 397.419 0.013
15.810 397.215 0.014 -605.63 1.82 397.427 0.014
15.909 397.207 0.011 -605.39 2.27 397.419 0.011
15.945 397.219 0.016 -606.59 2.18 397.431 0.016

14 D842554    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
15.518 397.675 0.009 -904.74 1.77 397.887 0.009
15.523 397.681 0.012 -900.94 1.85 397.892 0.012
15.654 397.669 0.010 -903.00 2.50 397.880 0.010
15.659 397.668 0.011 -907.04 1.73 397.879 0.011
15.789 397.685 0.010 -904.39 2.83 397.897 0.010
15.794 397.683 0.012 -907.65 1.82 397.894 0.012
15.924 397.680 0.014 -902.63 2.70 397.891 0.014
15.930 397.684 0.016 -906.33 1.82 397.895 0.016
