UEA CRAM Lab O2 and CO2 calibration results
RUN = 171220a
PROCESSED: 16:41:58 Mon 21Aug2023

Notes
Logfile

Results

Using data from 355.06 to 355.569 (Day of Year and Day Fraction)
(Position, CylinderID, SIO_CO2, SIO_CO2_sigma, SIO_CO2_slope, GMD_CO2, GMD_CO2_sigma, GMD_CO2_slope, CO2_n, d(O2/N2), d(O2/N2)_sigma, d(O2/N2)_slope, d(O2/N2)_n)

2 D88471 380.208 0.016 -0.073 380.427 0.016 -0.073 7 -419.31 2.17 -12.73 7
4 D88534 416.298 0.005 -0.019 416.485 0.005 -0.019 7 -745.29 0.90 -5.08 7
6 D88474 409.336 0.008 -0.003 409.531 0.008 -0.003 7 -536.23 2.61 -9.87 7
7 D596277 398.239 0.002 0.004 398.450 0.002 0.004 7 -751.44 0.59 -2.78 7
8 D88535 439.207 0.017 0.017 439.414 0.017 0.017 7 -510.66 1.11 -4.97 7
10 D548337 340.781 0.211 -0.818 340.753 0.212 -0.817 7 -161.39 2.09 -9.57 7
11 D88536 397.207 0.005 0.019 397.419 0.005 0.019 7 -604.44 0.95 -5.54 7
14 D842554 397.711 0.038 -0.048 397.922 0.038 -0.048 7 -900.71 2.87 -8.48 7
15 D548330 925.550 10.429 49.998 952.190 10.440 49.984 7 -1417.47 14.23 70.92 7
WT D258964 397.420 0.005 -0.012 397.631 0.005 -0.012 98 -748.20 0.62 -3.82 98
Text File

Raw Data and Diagnostics Figures

CO2 Timeseries
 CO2 Averages for Unknowns
 CO2 Averages for Knowns
Jog Ave. Diagnostics 1
 Jog Ave. Diagnostics 2
 Jog Std. Dev. Diagnostics
Jog Slope Diagnostics
 Rollover Effect
 Flushing Effect
CO2 Parameters
 CO2 Results
 O2 Timeseries
O2 Averages for Unknowns
 O2 Averages for Knowns
 O2 Parameters
O2 Results
 Residuals

Reference Cylinders, Assigned Concentrations, and Calculated Offsets from Fit

(Position, Cylinder ID, SIO CO2 in ppm, SIO Delta-CO2, SIO CO2 sigma, GMD CO2 in ppm, GMD Delta-CO2, GMD CO2 sigma, CO2 n, d(O2/N2) in per meg, Delta-d(O2/N2), d(O2/N2) sigma, d(O2/N2) n, Plots)

3 D073409 398.707 -0.009 0.001 398.918 -0.011 0.001 7 -651.78 3.02 0.92 7    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2    CO2 Fits 3   O2 Fits 3
5 D089507 428.087 -0.012 0.002 428.275 -0.014 0.002 7 -559.23 0.48 0.78 7    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2
9 D073419 440.065 0.004 0.001 440.275 0.005 0.001 7 -919.32 -1.23 0.39 7    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2
12 D073418 413.092 0.016 0.007 413.280 0.018 0.007 7 -779.40 -0.05 1.13 7    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2
13 D801299 381.475 0.002 0.001 381.695 0.002 0.001 7 -477.75 -2.33 0.77 7    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2

Measured Cylinders and Calculated Concentrations

(Position, Cylinder ID, Plots)
(Day of Year and Day Fraction, SIO CO2 in ppm, SD CO2 (ppm), d(O2/N2) in per meg, SD d(O2/N2) (per meg), GMD CO2 in ppm, SD CO2 (ppm), Plots)

2 D88471    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
354.989 380.268 0.012 -408.48 2.10 380.488 0.012
355.130 380.218 0.011 -417.46 1.90 380.437 0.011
355.135 380.228 0.014 -416.48 2.01 380.447 0.014
355.275 380.207 0.015 -419.61 1.79 380.426 0.015
355.281 380.199 0.011 -417.67 1.69 380.419 0.011
355.421 380.208 0.012 -421.11 1.82 380.428 0.012
355.427 380.218 0.014 -420.38 1.81 380.437 0.014
355.567 380.178 0.013 -422.43 2.52 380.397 0.013

4 D88534    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
354.999 416.295 0.015 -741.65 2.21 416.482 0.015
355.119 416.297 0.009 -744.31 2.26 416.484 0.009
355.145 416.305 0.008 -743.90 2.46 416.492 0.008
355.265 416.301 0.010 -745.37 2.19 416.488 0.010
355.291 416.298 0.011 -745.47 2.40 416.485 0.011
355.411 416.295 0.009 -746.20 2.06 416.482 0.009
355.437 416.301 0.011 -745.51 2.23 416.489 0.011
355.557 416.290 0.011 -746.29 1.85 416.477 0.011

6 D88474    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
355.010 409.336 0.011 -530.05 2.18 409.530 0.011
355.109 409.338 0.015 -530.38 2.29 409.533 0.015
355.156 409.344 0.012 -537.40 2.01 409.539 0.012
355.255 409.322 0.016 -536.72 2.07 409.517 0.016
355.302 409.334 0.013 -537.34 2.37 409.528 0.013
355.400 409.334 0.012 -537.34 1.88 409.529 0.012
355.447 409.345 0.015 -536.74 2.51 409.540 0.015
355.546 409.333 0.014 -537.71 2.40 409.528 0.014

7 D596277    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
355.015 398.231 0.012 -746.51 2.75 398.441 0.012
355.104 398.240 0.013 -750.93 1.81 398.450 0.013
355.161 398.239 0.009 -750.73 2.36 398.450 0.009
355.249 398.237 0.014 -751.01 2.19 398.448 0.014
355.307 398.239 0.014 -751.72 1.67 398.449 0.014
355.395 398.238 0.010 -752.37 2.03 398.448 0.010
355.453 398.240 0.011 -751.44 2.14 398.450 0.011
355.541 398.242 0.011 -751.87 2.21 398.452 0.011

8 D88535    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
355.020 439.198 0.013 -504.01 2.11 439.405 0.013
355.098 439.214 0.012 -509.23 2.37 439.421 0.012
355.166 439.200 0.013 -509.33 1.67 439.408 0.013
355.244 439.216 0.010 -511.24 2.33 439.423 0.010
355.312 439.188 0.012 -510.91 2.26 439.395 0.012
355.390 439.207 0.011 -511.94 2.05 439.415 0.011
355.458 439.187 0.013 -510.15 2.58 439.395 0.013
355.536 439.236 0.017 -511.79 2.05 439.444 0.017

10 D548337    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
355.031 341.375 0.012 -149.71 2.15 341.347 0.012
355.088 340.946 0.008 -157.35 2.72 340.918 0.008
355.177 341.007 0.013 -161.91 2.67 340.980 0.013
355.234 340.745 0.013 -159.81 1.94 340.716 0.013
355.322 340.856 0.012 -163.26 1.92 340.828 0.012
355.380 340.493 0.015 -162.48 2.08 340.465 0.015
355.468 340.921 0.014 -162.68 2.36 340.893 0.014
355.525 340.498 0.010 -162.21 2.32 340.470 0.010

11 D88536    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
355.036 397.192 0.019 -598.72 2.09 397.403 0.019
355.083 397.203 0.012 -603.08 2.02 397.414 0.012
355.182 397.198 0.011 -604.04 1.90 397.410 0.011
355.229 397.210 0.011 -603.77 1.61 397.422 0.011
355.328 397.206 0.011 -604.07 2.25 397.417 0.011
355.374 397.215 0.008 -605.44 1.94 397.426 0.008
355.473 397.208 0.013 -605.08 2.35 397.420 0.013
355.520 397.208 0.010 -605.64 2.28 397.420 0.010

14 D842554    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
355.052 397.660 0.011 -902.11 2.15 397.871 0.011
355.067 397.750 0.018 -895.65 2.08 397.961 0.018
355.197 397.669 0.015 -899.30 2.14 397.880 0.015
355.213 397.734 0.013 -904.19 2.71 397.945 0.013
355.343 397.666 0.013 -900.86 1.97 397.877 0.013
355.359 397.742 0.012 -902.90 2.34 397.953 0.012
355.489 397.677 0.014 -899.51 2.21 397.888 0.014
355.505 397.740 0.010 -902.58 2.26 397.952 0.010

15 D548330    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
355.057 903.262 0.053 -1449.13 2.38 929.892 0.053
355.062 907.605 0.000 -1444.01 1.98 934.248 0.000
355.203 918.446 0.051 -1423.99 2.05 945.065 0.051
355.208 922.121 0.000 -1422.70 2.00 948.753 0.000
355.348 934.071 0.032 -1405.96 2.05 960.739 0.032
355.354 938.098 0.011 -1402.35 2.42 964.772 0.011
355.494 926.936 0.015 -1414.00 1.96 953.541 0.015
355.499 931.576 0.040 -1409.26 2.37 958.213 0.040
