UEA CRAM Lab O2 and CO2 calibration results
RUN = 170323a
PROCESSED: 10:13:26 Fri 4Aug2023

Notes
Logfile

Results

Using data from 82.902 to 83.213 (Day of Year and Day Fraction)
(Position, CylinderID, SIO_CO2, SIO_CO2_sigma, SIO_CO2_slope, GMD_CO2, GMD_CO2_sigma, GMD_CO2_slope, CO2_n, d(O2/N2), d(O2/N2)_sigma, d(O2/N2)_slope, d(O2/N2)_n)

2 CA07857 362.036 0.021 0.082 361.610 0.021 0.089 5 NA NA NA 0
3 D078943 391.298 0.012 0.030 391.436 0.012 0.029 5 -564.59 1.40 1.43 5
5 D251511 413.362 0.015 -0.062 412.753 0.014 -0.060 4 -789.80 1.89 8.42 5
6 CA07809 400.200 0.004 -0.007 400.034 0.004 -0.006 5 NA NA NA 0
10 CA07825 432.089 0.012 0.059 431.417 0.012 0.056 5 NA NA NA 0
12 D073418 414.179 0.014 0.090 413.549 0.014 0.088 5 -781.73 1.62 -2.29 5
13 D801299 381.289 0.007 -0.058 381.630 0.007 -0.057 5 -478.32 1.24 -3.26 5
15 D073419 440.793 0.012 0.087 440.579 0.013 0.091 5 -915.30 2.89 17.63 5
WT D258964 397.879 0.005 -0.046 397.797 0.005 -0.044 60 -749.16 1.08 11.29 60
Text File

Raw Data and Diagnostics Figures

CO2 Timeseries
 CO2 Averages for Unknowns
 CO2 Averages for Knowns
Jog Ave. Diagnostics 1
 Jog Ave. Diagnostics 2
 Jog Std. Dev. Diagnostics
Jog Slope Diagnostics
 Rollover Effect
 Flushing Effect
CO2 Parameters
 CO2 Results
 O2 Timeseries
O2 Averages for Unknowns
 O2 Averages for Knowns
 O2 Parameters
O2 Results
 Residuals

Reference Cylinders, Assigned Concentrations, and Calculated Offsets from Fit

(Position, Cylinder ID, SIO CO2 in ppm, SIO Delta-CO2, SIO CO2 sigma, GMD CO2 in ppm, GMD Delta-CO2, GMD CO2 sigma, CO2 n, d(O2/N2) in per meg, Delta-d(O2/N2), d(O2/N2) sigma, d(O2/N2) n, Plots)

1 ND12042 399.283 0.000 0.000 399.150 0.000 0.000 5 -384.25 3.18 0.32 5    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2
7 ND19515 450.346 0.000 0.000 451.248 0.000 0.000 5 -707.13 -1.50 0.38 5    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2
8 CC71581 388.340 0.000 0.000 388.560 0.000 0.000 5 -454.95 1.42 0.82 5    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2
9 ND19677 370.558 0.000 0.000 370.748 0.000 0.000 3 -256.57 -2.98 0.36 4    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2

Measured Cylinders and Calculated Concentrations

(Position, Cylinder ID, Plots)
(Day of Year and Day Fraction, SIO CO2 in ppm, SD CO2 (ppm), d(O2/N2) in per meg, SD d(O2/N2) (per meg), GMD CO2 in ppm, SD CO2 (ppm), Plots)

2 CA07857    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
82.836 362.036 0.015 -4626.05 10.07 361.606 0.015
82.847 362.050 0.014 -4616.40 9.68 361.622 0.014
82.956 362.020 0.013 -4603.23 9.58 361.595 0.013
82.972 362.015 0.010 -4597.79 9.59 361.588 0.010
83.081 362.060 0.009 -4599.47 9.58 361.633 0.009
83.097 362.058 0.016 -4599.99 9.56 361.632 0.016
83.206 362.027 0.011 -4589.15 9.66 361.603 0.011

3 D078943    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
82.852 391.301 0.010 -560.22 2.03 391.439 0.010
82.951 391.300 0.015 -565.33 2.05 391.438 0.015
82.977 391.292 0.011 -563.77 1.90 391.430 0.011
83.076 391.310 0.011 -566.45 2.49 391.447 0.011
83.102 391.281 0.014 -562.80 1.69 391.419 0.014
83.201 391.308 0.010 -564.59 2.41 391.446 0.010

5 D251511    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
82.857 413.380 0.012 -789.98 1.43 412.770 0.012
82.946 413.339 0.023 -792.35 2.43 412.731 0.023
82.982 413.357 0.013 -789.42 1.71 412.748 0.013
83.071 413.381 0.011 -791.09 1.71 412.772 0.011
83.107 413.364 0.013 -788.05 2.25 412.755 0.013
83.196 413.346 0.015 -788.09 1.96 412.738 0.015

6 CA07809    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
82.862 400.198 0.012 -4608.12 9.79 400.031 0.012
82.941 400.202 0.014 -4590.90 9.75 400.035 0.014
82.987 400.195 0.015 -4578.22 9.76 400.029 0.015
83.066 400.207 0.011 -4581.93 9.77 400.040 0.011
83.112 400.199 0.008 -4583.94 9.72 400.033 0.008
83.191 400.197 0.014 -4572.60 9.79 400.031 0.014

10 CA07825    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
82.883 432.097 0.013 -4714.06 10.45 431.425 0.013
82.920 432.080 0.015 -4706.50 10.45 431.409 0.015
83.008 432.079 0.013 -4688.80 10.50 431.406 0.013
83.045 432.097 0.012 -4691.42 10.45 431.424 0.012
83.133 432.107 0.011 -4695.02 10.35 431.434 0.011
83.170 432.083 0.015 -4689.05 10.44 431.412 0.015

12 D073418    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
82.888 414.174 0.012 -783.29 2.30 413.544 0.012
82.915 414.167 0.013 -781.43 1.33 413.538 0.013
83.013 414.162 0.013 -782.70 1.91 413.532 0.013
83.040 414.192 0.015 -779.93 1.89 413.561 0.015
83.138 414.194 0.013 -783.96 1.82 413.564 0.013
83.165 414.181 0.017 -780.61 2.08 413.551 0.017

13 D801299    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
82.894 381.283 0.013 -478.95 1.88 381.624 0.013
82.909 381.296 0.018 -477.98 1.56 381.637 0.018
83.019 381.289 0.011 -478.92 2.07 381.630 0.011
83.034 381.296 0.012 -477.03 1.71 381.637 0.012
83.144 381.282 0.013 -480.16 2.01 381.623 0.013
83.159 381.283 0.013 -477.53 2.14 381.624 0.013

15 D073419    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
82.899 440.755 0.012 -923.49 1.87 440.539 0.012
82.904 440.783 0.015 -920.25 1.72 440.569 0.015
83.024 440.778 0.011 -913.09 1.84 440.562 0.011
83.029 440.798 0.012 -913.81 2.11 440.584 0.012
83.149 440.803 0.017 -913.96 2.02 440.590 0.017
83.154 440.802 0.011 -915.38 1.75 440.589 0.011
