UEA CRAM Lab O2 and CO2 calibration results
RUN = 151007d
PROCESSED: 11:38:59 Wed 2Aug2023

Notes
Logfile

Results

Using data from 280.99 to 281.425 (Day of Year and Day Fraction)
(Position, CylinderID, SIO_CO2, SIO_CO2_sigma, SIO_CO2_slope, GMD_CO2, GMD_CO2_sigma, GMD_CO2_slope, CO2_n, d(O2/N2), d(O2/N2)_sigma, d(O2/N2)_slope, d(O2/N2)_n)

1 ND12042 398.923 0.012 -0.040 399.134 0.012 -0.040 7 -382.28 0.47 1.73 7
3 CC180655 358.442 0.016 -0.066 358.560 0.016 -0.066 7 -415.44 0.68 2.73 7
4 CC178269 359.578 0.012 0.033 359.705 0.012 0.034 7 -238.57 0.70 3.95 7
5 D743657 399.765 0.005 0.022 399.975 0.005 0.022 7 -545.93 1.84 4.15 7
7 ND19515 450.562 0.089 0.108 450.818 0.089 0.107 7 -720.86 0.75 3.83 7
9 ND19677 370.557 0.023 0.047 370.749 0.023 0.047 7 -254.02 0.76 2.74 7
11 D089506 402.789 0.007 0.016 402.995 0.007 0.016 7 -593.90 0.70 -2.28 7
12 D273561 412.706 0.007 -0.033 412.899 0.007 -0.033 7 -767.84 0.76 -3.12 7
WT D273554 438.141 0.014 0.007 438.345 0.014 0.006 84 -819.41 0.56 2.51 84
Text File

Raw Data and Diagnostics Figures

CO2 Timeseries
 CO2 Averages for Unknowns
 CO2 Averages for Knowns
Jog Ave. Diagnostics 1
 Jog Ave. Diagnostics 2
 Jog Std. Dev. Diagnostics
Jog Slope Diagnostics
 Rollover Effect
 Flushing Effect
CO2 Parameters
 CO2 Results
 O2 Timeseries
O2 Averages for Unknowns
 O2 Averages for Knowns
 O2 Parameters
O2 Results
 Residuals

Reference Cylinders, Assigned Concentrations, and Calculated Offsets from Fit

(Position, Cylinder ID, SIO CO2 in ppm, SIO Delta-CO2, SIO CO2 sigma, GMD CO2 in ppm, GMD Delta-CO2, GMD CO2 sigma, CO2 n, d(O2/N2) in per meg, Delta-d(O2/N2), d(O2/N2) sigma, d(O2/N2) n, Plots)

2 CA07857 361.230 0.000 0.000 361.370 0.000 0.000 6 -4698.75 11.26 0.24 7    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2    CO2 Fits 3   O2 Fits 3
6 CA07809 399.820 0.000 0.000 400.030 0.000 0.000 7 -4670.85 -0.92 0.58 7    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2
8 CC71581 388.340 0.000 0.000 388.560 0.000 0.000 7 -454.95 -0.40 0.02 7    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2
10 CA07825 430.810 0.000 0.000 431.000 0.000 0.000 7 -4777.54 -10.00 0.37 7    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2

Measured Cylinders and Calculated Concentrations

(Position, Cylinder ID, Plots)
(Day of Year and Day Fraction, SIO CO2 in ppm, SD CO2 (ppm), d(O2/N2) in per meg, SD d(O2/N2) (per meg), GMD CO2 in ppm, SD CO2 (ppm), Plots)

1 ND12042    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
280.928 398.909 0.017 -381.88 1.69 399.120 0.017
281.048 398.923 0.010 -382.79 1.99 399.134 0.010
281.053 398.936 0.009 -382.71 1.88 399.147 0.009
281.173 398.914 0.012 -381.85 1.55 399.125 0.012
281.178 398.927 0.012 -382.62 1.96 399.138 0.012
281.298 398.916 0.013 -381.67 1.85 399.127 0.013
281.303 398.938 0.019 -381.85 2.16 399.150 0.019
281.424 398.906 0.014 -382.46 1.88 399.117 0.014

3 CC180655    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
280.939 358.449 0.016 -413.98 1.72 358.566 0.016
281.038 358.466 0.018 -416.42 2.27 358.584 0.018
281.064 358.429 0.019 -416.07 1.95 358.547 0.019
281.163 358.445 0.013 -415.22 1.84 358.562 0.013
281.189 358.450 0.013 -415.06 1.56 358.568 0.013
281.288 358.447 0.015 -414.38 1.86 358.565 0.015
281.314 358.440 0.016 -415.29 1.75 358.558 0.016
281.413 358.417 0.015 -415.61 1.63 358.535 0.015

4 CC178269    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
280.944 359.573 0.025 -237.63 1.68 359.700 0.025
281.032 359.588 0.015 -239.85 2.16 359.716 0.015
281.069 359.556 0.014 -238.97 2.05 359.683 0.014
281.157 359.584 0.014 -238.84 2.01 359.711 0.014
281.194 359.569 0.012 -237.87 1.85 359.696 0.012
281.282 359.583 0.013 -238.00 1.75 359.711 0.013
281.319 359.574 0.011 -238.22 2.06 359.701 0.011
281.408 359.591 0.016 -238.22 2.34 359.719 0.016

5 D743657    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
280.949 399.756 0.017 -551.32 2.27 399.966 0.017
281.027 399.764 0.017 -549.69 2.06 399.974 0.017
281.074 399.760 0.011 -545.27 2.05 399.970 0.011
281.152 399.769 0.018 -544.80 2.46 399.979 0.018
281.199 399.763 0.015 -543.87 2.42 399.973 0.015
281.277 399.762 0.016 -545.54 2.32 399.972 0.016
281.324 399.765 0.017 -546.11 1.80 399.975 0.017
281.403 399.775 0.013 -546.24 1.87 399.985 0.013

7 ND19515    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
280.960 450.438 0.020 -720.55 2.21 450.694 0.020
281.017 450.620 0.011 -722.26 1.91 450.877 0.011
281.085 450.491 0.017 -721.08 1.66 450.748 0.017
281.142 450.582 0.012 -720.08 1.80 450.838 0.012
281.210 450.458 0.014 -721.24 2.48 450.714 0.014
281.267 450.615 0.011 -720.56 1.85 450.872 0.011
281.335 450.472 0.013 -720.59 1.98 450.728 0.013
281.392 450.693 0.014 -720.18 1.58 450.949 0.014

9 ND19677    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
280.970 370.529 0.014 -253.99 2.10 370.721 0.014
281.006 370.564 0.011 -255.69 2.13 370.756 0.011
281.095 370.532 0.013 -253.36 2.37 370.724 0.013
281.131 370.568 0.010 -253.65 1.73 370.760 0.010
281.220 370.534 0.012 -253.96 1.94 370.725 0.012
281.256 370.569 0.010 -253.76 1.64 370.761 0.010
281.345 370.540 0.012 -253.98 1.79 370.732 0.012
281.381 370.595 0.015 -253.72 1.86 370.787 0.015

11 D089506    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
280.980 402.790 0.016 -594.28 2.18 402.996 0.016
280.996 402.785 0.011 -593.13 1.81 402.991 0.011
281.105 402.799 0.019 -594.24 1.72 403.005 0.019
281.121 402.781 0.015 -593.61 1.94 402.987 0.015
281.230 402.791 0.015 -594.77 1.67 402.997 0.015
281.246 402.781 0.015 -592.92 2.11 402.987 0.015
281.355 402.797 0.013 -594.54 2.18 403.003 0.013
281.371 402.790 0.017 -594.06 1.97 402.996 0.017

12 D273561    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
280.986 412.718 0.012 -768.53 2.31 412.910 0.012
280.991 412.712 0.017 -766.75 1.87 412.905 0.017
281.111 412.712 0.012 -767.82 1.89 412.905 0.012
281.116 412.713 0.013 -767.94 1.89 412.906 0.013
281.236 412.694 0.016 -768.40 1.89 412.887 0.016
281.241 412.707 0.014 -767.42 1.67 412.900 0.014
281.361 412.702 0.011 -769.11 1.67 412.895 0.011
281.366 412.703 0.018 -767.42 1.90 412.896 0.018
