UEA CRAM Lab O2 and CO2 calibration results
RUN = 130807a
PROCESSED: 13:14:21 Tue 1Aug2023

Notes
Logfile

Results

Using data from 219.65 to 220.013 (Day of Year and Day Fraction)
(Position, CylinderID, SIO_CO2, SIO_CO2_sigma, SIO_CO2_slope, GMD_CO2, GMD_CO2_sigma, GMD_CO2_slope, CO2_n, d(O2/N2), d(O2/N2)_sigma, d(O2/N2)_slope, d(O2/N2)_n)

2 D88534 417.109 0.022 -0.046 416.423 0.021 -0.044 7 -739.81 2.79 -14.20 7
3 D88535 439.610 0.026 -0.054 439.359 0.027 -0.052 7 -510.67 3.09 9.06 7
4 D255734 399.721 0.005 -0.002 399.572 0.005 -0.002 7 -601.15 1.27 -1.08 7
6 D596276 403.004 0.011 0.021 402.735 0.010 0.021 7 -616.73 1.84 8.75 7
10 D88536 397.421 0.010 -0.040 397.355 0.009 -0.038 7 -599.26 1.78 4.65 7
11 D88532 389.441 0.012 -0.047 389.632 0.011 -0.046 7 -623.81 1.39 2.74 7
WT D743660 408.706 0.014 -0.016 408.240 0.013 -0.016 70 -663.60 0.78 -2.74 70
Text File

Raw Data and Diagnostics Figures

CO2 Timeseries
 CO2 Averages for Unknowns
 CO2 Averages for Knowns
Jog Ave. Diagnostics 1
 Jog Ave. Diagnostics 2
 Jog Std. Dev. Diagnostics
Jog Slope Diagnostics
 Rollover Effect
 Flushing Effect
CO2 Parameters
 CO2 Results
 O2 Timeseries
O2 Averages for Unknowns
 O2 Averages for Knowns
 O2 Parameters
O2 Results
 Residuals

Reference Cylinders, Assigned Concentrations, and Calculated Offsets from Fit

(Position, Cylinder ID, SIO CO2 in ppm, SIO Delta-CO2, SIO CO2 sigma, GMD CO2 in ppm, GMD Delta-CO2, GMD CO2 sigma, CO2 n, d(O2/N2) in per meg, Delta-d(O2/N2), d(O2/N2) sigma, d(O2/N2) n, Plots)

1 ND12042 399.283 0.000 0.000 399.150 0.000 0.000 7 -384.25 3.17 0.51 7    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2
7 ND19515 450.346 0.000 0.000 451.248 0.000 0.000 7 -707.13 -1.63 0.40 7    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2
8 CC71581 388.340 0.000 0.000 388.560 0.000 0.000 7 -454.95 1.89 0.92 7    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2
9 ND19677 370.558 0.000 0.000 370.748 0.000 0.000 7 -256.57 -3.38 0.66 7    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2

Measured Cylinders and Calculated Concentrations

(Position, Cylinder ID, Plots)
(Day of Year and Day Fraction, SIO CO2 in ppm, SD CO2 (ppm), d(O2/N2) in per meg, SD d(O2/N2) (per meg), GMD CO2 in ppm, SD CO2 (ppm), Plots)

2 D88534    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2    CO2 Fits 3   O2 Fits 3
219.595 416.828 0.021 -842.07 29.03 416.147 0.021
219.606 417.073 0.012 -736.28 6.19 416.388 0.012
219.694 417.117 0.014 -735.70 6.05 416.430 0.014
219.710 417.143 0.008 -736.36 7.86 416.456 0.008
219.798 417.094 0.010 -742.76 7.07 416.409 0.010
219.814 417.083 0.011 -741.81 5.97 416.398 0.011
219.903 417.118 0.012 -741.96 8.28 416.432 0.012
219.918 417.085 0.012 -739.60 6.10 416.400 0.012
220.007 417.121 0.016 -740.52 7.20 416.435 0.016

3 D88535    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
219.611 439.592 0.020 -506.64 7.38 439.341 0.020
219.689 439.603 0.011 -512.82 6.44 439.351 0.011
219.715 439.663 0.011 -506.90 6.82 439.413 0.011
219.793 439.579 0.011 -512.43 6.00 439.328 0.011
219.819 439.593 0.009 -515.37 8.45 439.341 0.009
219.897 439.612 0.015 -510.60 7.47 439.361 0.015
219.923 439.616 0.013 -509.31 7.21 439.366 0.013
220.001 439.604 0.009 -507.28 6.71 439.352 0.009

4 D255734    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
219.616 399.711 0.011 -603.06 6.57 399.562 0.011
219.684 399.716 0.013 -601.79 6.64 399.567 0.013
219.720 399.727 0.011 -598.79 6.48 399.578 0.011
219.788 399.717 0.010 -601.39 7.39 399.569 0.010
219.824 399.728 0.008 -602.62 7.62 399.579 0.008
219.892 399.723 0.015 -602.16 8.46 399.574 0.015
219.929 399.715 0.014 -600.58 7.19 399.566 0.014
219.996 399.722 0.009 -600.72 5.99 399.573 0.009

6 D596276    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
219.621 403.010 0.013 -611.80 7.99 402.741 0.013
219.679 403.010 0.014 -616.81 5.87 402.741 0.014
219.725 402.988 0.014 -619.37 9.10 402.720 0.014
219.783 403.004 0.010 -615.08 6.99 402.735 0.010
219.830 403.005 0.012 -619.03 7.34 402.736 0.012
219.887 403.015 0.011 -616.38 6.24 402.746 0.011
219.934 402.991 0.012 -615.80 6.28 402.723 0.012
219.991 403.014 0.013 -614.63 6.35 402.745 0.013

10 D88536    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
219.642 397.429 0.013 -594.03 6.70 397.363 0.013
219.658 397.436 0.014 -599.17 6.64 397.370 0.014
219.746 397.410 0.013 -601.42 6.63 397.345 0.013
219.762 397.423 0.011 -598.46 7.54 397.357 0.011
219.850 397.418 0.010 -600.61 6.15 397.352 0.010
219.866 397.430 0.010 -598.20 6.62 397.364 0.010
219.955 397.411 0.014 -600.66 5.41 397.345 0.014
219.970 397.420 0.019 -596.29 5.33 397.354 0.019

11 D88532    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
219.647 389.473 0.012 -622.27 7.79 389.663 0.012
219.653 389.465 0.015 -622.48 7.16 389.656 0.015
219.751 389.426 0.011 -626.12 7.39 389.618 0.011
219.757 389.437 0.013 -625.02 6.57 389.629 0.013
219.856 389.441 0.010 -624.23 6.24 389.633 0.010
219.861 389.439 0.014 -622.34 7.01 389.630 0.014
219.960 389.439 0.012 -623.05 5.86 389.630 0.012
219.965 389.437 0.011 -623.43 6.85 389.628 0.011
