UEA CRAM Lab O2 and CO2 calibration results
RUN = 130805a
PROCESSED: 13:14:37 Tue 1Aug2023

Notes
Logfile

Results

Using data from 217.545 to 217.909 (Day of Year and Day Fraction)
(Position, CylinderID, SIO_CO2, SIO_CO2_sigma, SIO_CO2_slope, GMD_CO2, GMD_CO2_sigma, GMD_CO2_slope, CO2_n, d(O2/N2), d(O2/N2)_sigma, d(O2/N2)_slope, d(O2/N2)_n)

2 D88534 417.066 0.017 0.082 416.381 0.016 0.080 7 -740.06 0.82 -1.54 7
3 D88535 439.563 0.021 0.098 439.313 0.020 0.094 7 -509.96 1.16 -7.97 7
4 D255734 399.712 0.011 0.057 399.563 0.010 0.055 7 -601.12 1.29 -5.59 7
6 D596276 402.986 0.013 0.067 402.718 0.012 0.064 7 -615.65 1.13 6.37 7
10 D88536 397.406 0.012 0.061 397.341 0.012 0.059 7 -600.62 1.54 4.88 7
11 D88532 389.435 0.006 0.004 389.626 0.006 0.003 7 -624.02 1.99 -4.62 7
WT D743660 408.737 0.014 0.080 408.270 0.014 0.077 70 -662.84 1.17 -10.14 70
Text File

Raw Data and Diagnostics Figures

CO2 Timeseries
 CO2 Averages for Unknowns
 CO2 Averages for Knowns
Jog Ave. Diagnostics 1
 Jog Ave. Diagnostics 2
 Jog Std. Dev. Diagnostics
Jog Slope Diagnostics
 Rollover Effect
 Flushing Effect
CO2 Parameters
 CO2 Results
 O2 Timeseries
O2 Averages for Unknowns
 O2 Averages for Knowns
 O2 Parameters
O2 Results
 Residuals

Reference Cylinders, Assigned Concentrations, and Calculated Offsets from Fit

(Position, Cylinder ID, SIO CO2 in ppm, SIO Delta-CO2, SIO CO2 sigma, GMD CO2 in ppm, GMD Delta-CO2, GMD CO2 sigma, CO2 n, d(O2/N2) in per meg, Delta-d(O2/N2), d(O2/N2) sigma, d(O2/N2) n, Plots)

1 ND12042 399.283 0.000 0.000 399.150 0.000 0.000 7 -384.25 2.12 0.71 6    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2
7 ND19515 450.346 0.000 0.000 451.248 0.000 0.000 7 -707.13 -1.40 0.32 7    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2
8 CC71581 388.340 0.000 0.000 388.560 0.000 0.000 7 -454.95 1.97 0.91 7    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2
9 ND19677 370.558 0.000 0.000 370.748 0.000 0.000 7 -256.57 -2.75 0.64 7    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2

Measured Cylinders and Calculated Concentrations

(Position, Cylinder ID, Plots)
(Day of Year and Day Fraction, SIO CO2 in ppm, SD CO2 (ppm), d(O2/N2) in per meg, SD d(O2/N2) (per meg), GMD CO2 in ppm, SD CO2 (ppm), Plots)

2 D88534    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2    CO2 Fits 3   O2 Fits 3
217.491 416.858 0.029 -844.57 31.16 416.178 0.029
217.501 417.038 0.010 -737.54 8.54 416.355 0.010
217.590 417.064 0.011 -739.95 8.33 416.380 0.011
217.606 417.047 0.011 -739.83 5.49 416.363 0.011
217.694 417.041 0.010 -739.87 7.52 416.358 0.010
217.710 417.072 0.014 -740.61 6.66 416.387 0.014
217.798 417.079 0.011 -740.58 8.31 416.393 0.011
217.814 417.088 0.008 -738.52 6.30 416.403 0.008
217.902 417.068 0.009 -741.07 7.46 416.384 0.009

3 D88535    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
217.507 439.544 0.015 -507.37 7.97 439.292 0.015
217.585 439.554 0.011 -508.01 9.03 439.303 0.011
217.611 439.541 0.015 -509.36 7.85 439.291 0.015
217.689 439.537 0.011 -510.51 6.77 439.288 0.011
217.715 439.586 0.009 -510.04 5.50 439.336 0.009
217.793 439.575 0.012 -509.35 6.84 439.324 0.012
217.819 439.588 0.011 -511.23 5.82 439.336 0.011
217.897 439.562 0.012 -511.21 6.07 439.311 0.012

4 D255734    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
217.512 399.709 0.012 -597.48 7.56 399.561 0.012
217.579 399.709 0.014 -601.09 8.92 399.561 0.014
217.616 399.698 0.013 -599.93 6.03 399.550 0.013
217.684 399.704 0.011 -600.24 7.46 399.555 0.011
217.720 399.713 0.012 -600.06 6.46 399.565 0.012
217.788 399.715 0.009 -603.67 6.42 399.566 0.009
217.824 399.732 0.013 -601.34 7.12 399.582 0.013
217.892 399.712 0.011 -601.54 6.96 399.564 0.011

6 D596276    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
217.517 402.983 0.009 -611.50 8.19 402.715 0.009
217.574 402.990 0.011 -617.73 8.75 402.722 0.011
217.621 402.967 0.012 -614.72 7.42 402.700 0.012
217.678 402.972 0.011 -616.44 7.02 402.705 0.011
217.725 402.995 0.012 -615.37 5.85 402.727 0.012
217.783 402.982 0.011 -615.36 7.64 402.714 0.011
217.829 402.996 0.010 -615.61 6.33 402.728 0.010
217.887 403.000 0.009 -614.36 5.97 402.732 0.009

10 D88536    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
217.538 397.406 0.015 -599.12 9.27 397.340 0.015
217.553 397.405 0.011 -602.63 8.47 397.340 0.011
217.642 397.388 0.012 -599.37 7.73 397.324 0.012
217.658 397.392 0.014 -601.09 7.87 397.327 0.014
217.746 397.415 0.012 -599.18 7.23 397.349 0.012
217.762 397.421 0.013 -601.45 5.16 397.355 0.013
217.850 397.410 0.011 -601.95 7.27 397.344 0.011
217.866 397.413 0.013 -598.65 6.19 397.348 0.013

11 D88532    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
217.543 389.450 0.010 -623.01 9.05 389.641 0.010
217.548 389.439 0.013 -623.52 9.10 389.630 0.013
217.647 389.432 0.015 -621.96 7.81 389.623 0.015
217.652 389.425 0.012 -624.15 6.07 389.617 0.012
217.751 389.439 0.010 -627.69 6.30 389.630 0.010
217.757 389.440 0.014 -622.08 7.83 389.631 0.014
217.856 389.430 0.010 -623.43 5.96 389.622 0.010
217.861 389.438 0.012 -625.28 8.31 389.629 0.012
