UEA CRAM Lab O2 and CO2 calibration results
RUN = 130801a
PROCESSED: 13:15:09 Tue 1Aug2023

Notes
Logfile

Results

Using data from 213.566 to 213.93 (Day of Year and Day Fraction)
(Position, CylinderID, SIO_CO2, SIO_CO2_sigma, SIO_CO2_slope, GMD_CO2, GMD_CO2_sigma, GMD_CO2_slope, CO2_n, d(O2/N2), d(O2/N2)_sigma, d(O2/N2)_slope, d(O2/N2)_n)

2 D88534 417.042 0.072 0.061 416.358 0.069 0.065 7 -737.41 0.87 -2.63 7
3 D88535 439.575 0.061 -0.231 439.324 0.061 -0.231 7 -507.55 1.90 -7.79 7
4 D255734 399.701 0.014 0.051 399.553 0.014 0.049 7 -602.20 1.93 9.06 7
6 D596276 402.993 0.013 -0.011 402.725 0.013 -0.010 7 -614.54 1.74 1.58 7
10 D88536 397.415 0.019 -0.046 397.349 0.018 -0.044 7 -600.56 2.50 18.88 6
11 D88532 389.430 0.012 -0.008 389.622 0.011 -0.008 7 -628.79 2.48 13.63 7
WT D743660 408.900 0.033 -0.209 408.428 0.032 -0.201 70 -659.86 1.79 -13.88 70
Text File

Raw Data and Diagnostics Figures

CO2 Timeseries
 CO2 Averages for Unknowns
 CO2 Averages for Knowns
Jog Ave. Diagnostics 1
 Jog Ave. Diagnostics 2
 Jog Std. Dev. Diagnostics
Jog Slope Diagnostics
 Rollover Effect
 Flushing Effect
CO2 Parameters
 CO2 Results
 O2 Timeseries
O2 Averages for Unknowns
 O2 Averages for Knowns
 O2 Parameters
O2 Results
 Residuals

Reference Cylinders, Assigned Concentrations, and Calculated Offsets from Fit

(Position, Cylinder ID, SIO CO2 in ppm, SIO Delta-CO2, SIO CO2 sigma, GMD CO2 in ppm, GMD Delta-CO2, GMD CO2 sigma, CO2 n, d(O2/N2) in per meg, Delta-d(O2/N2), d(O2/N2) sigma, d(O2/N2) n, Plots)

1 ND12042 399.283 0.000 0.000 399.150 0.000 0.000 7 -384.25 2.95 1.57 7    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2
7 ND19515 450.346 0.000 0.000 451.248 0.000 0.000 7 -707.13 -1.61 0.69 7    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2
8 CC71581 388.340 0.000 0.000 388.560 0.000 0.000 7 -454.95 2.13 1.17 7    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2
9 ND19677 370.558 0.000 0.000 370.748 0.000 0.000 7 -256.57 -3.19 1.49 7    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2

Measured Cylinders and Calculated Concentrations

(Position, Cylinder ID, Plots)
(Day of Year and Day Fraction, SIO CO2 in ppm, SD CO2 (ppm), d(O2/N2) in per meg, SD d(O2/N2) (per meg), GMD CO2 in ppm, SD CO2 (ppm), Plots)

2 D88534    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
213.522 417.083 0.013 -736.03 7.13 416.398 0.013
213.610 416.954 0.009 -738.35 7.34 416.271 0.009
213.626 417.056 0.012 -736.45 7.07 416.371 0.012
213.715 417.016 0.008 -736.90 5.97 416.332 0.008
213.730 417.100 0.012 -737.11 7.08 416.414 0.012
213.819 417.091 0.011 -737.53 7.87 416.404 0.011
213.835 417.129 0.010 -736.75 6.49 416.442 0.010
213.923 416.948 0.015 -738.80 7.34 416.268 0.015

3 D88535    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
213.527 439.597 0.011 -500.89 6.04 439.342 0.011
213.605 439.585 0.011 -504.94 9.80 439.333 0.011
213.631 439.595 0.015 -505.48 6.83 439.344 0.015
213.710 439.557 0.011 -508.32 6.60 439.306 0.011
213.736 439.604 0.014 -510.62 8.99 439.353 0.014
213.814 439.612 0.010 -507.92 5.34 439.361 0.010
213.840 439.629 0.015 -508.08 7.41 439.377 0.015
213.918 439.446 0.012 -507.44 6.66 439.195 0.012

4 D255734    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
213.532 399.702 0.015 -588.37 7.49 399.554 0.015
213.600 399.697 0.012 -604.97 5.96 399.549 0.012
213.636 399.694 0.016 -602.36 6.75 399.546 0.016
213.704 399.677 0.009 -602.10 7.16 399.530 0.009
213.741 399.723 0.016 -602.49 6.34 399.574 0.016
213.809 399.697 0.012 -602.32 8.79 399.549 0.012
213.845 399.708 0.011 -598.42 8.67 399.559 0.011
213.913 399.709 0.013 -602.76 10.19 399.560 0.013

6 D596276    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
213.537 403.026 0.010 -613.89 7.59 402.756 0.010
213.595 403.012 0.012 -614.37 8.42 402.743 0.012
213.642 402.980 0.014 -614.28 7.33 402.712 0.014
213.699 402.975 0.010 -613.59 11.48 402.707 0.010
213.746 403.004 0.012 -617.43 7.07 402.735 0.012
213.803 402.994 0.013 -615.74 7.90 402.726 0.013
213.850 402.998 0.012 -611.81 8.63 402.729 0.012
213.908 402.989 0.010 -614.53 6.48 402.721 0.010

10 D88536    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
213.558 397.436 0.010 -606.94 6.72 397.369 0.010
213.574 397.451 0.017 -603.75 6.59 397.384 0.017
213.663 397.390 0.012 -602.06 28.92 397.325 0.012
213.678 397.406 0.011 -602.08 8.06 397.341 0.011
213.767 397.406 0.017 -600.64 8.69 397.341 0.017
213.783 397.420 0.013 -600.98 5.95 397.354 0.013
213.871 397.414 0.010 -599.53 6.57 397.349 0.010
213.887 397.415 0.012 -596.37 6.26 397.349 0.012

11 D88532    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
213.564 389.438 0.015 -636.04 6.32 389.630 0.015
213.569 389.446 0.012 -630.55 6.70 389.637 0.012
213.668 389.410 0.009 -632.77 11.29 389.602 0.009
213.673 389.423 0.012 -627.44 8.11 389.615 0.012
213.772 389.435 0.013 -630.20 9.13 389.627 0.013
213.777 389.439 0.011 -627.10 6.16 389.630 0.011
213.876 389.427 0.011 -627.99 5.67 389.618 0.011
213.881 389.432 0.009 -625.51 7.96 389.623 0.009
