UEA CRAM Lab O2 and CO2 calibration results
RUN = 130724a
PROCESSED: 16:19:02 Tue 1Aug2023

Notes
Logfile

Results

Using data from 205.735 to 205.969 (Day of Year and Day Fraction)
(Position, CylinderID, SIO_CO2, SIO_CO2_sigma, SIO_CO2_slope, GMD_CO2, GMD_CO2_sigma, GMD_CO2_slope, CO2_n, d(O2/N2), d(O2/N2)_sigma, d(O2/N2)_slope, d(O2/N2)_n)

2 CC177837 359.048 0.018 0.088 358.316 0.019 0.097 5 -403.11 0.70 -9.33 4
3 CC177841 360.480 0.020 0.120 359.922 0.022 0.131 5 -247.29 1.18 -11.40 4
6 CC178444 379.082 0.016 0.048 379.430 0.015 0.049 5 -405.51 1.71 1.18 5
10 D88536 397.410 0.014 0.007 397.344 0.013 0.007 5 -603.41 2.48 4.54 5
11 D88532 389.425 0.013 0.090 389.617 0.012 0.087 5 -631.60 1.50 23.17 4
WT D743660 408.777 0.007 -0.017 408.309 0.006 -0.017 45 -660.81 0.81 -7.50 45
Text File

Raw Data and Diagnostics Figures

CO2 Timeseries
 CO2 Averages for Unknowns
 CO2 Averages for Knowns
Jog Ave. Diagnostics 1
 Jog Ave. Diagnostics 2
 Jog Std. Dev. Diagnostics
Jog Slope Diagnostics
 Rollover Effect
 Flushing Effect
CO2 Parameters
 CO2 Results
 O2 Timeseries
O2 Averages for Unknowns
 O2 Averages for Knowns
 O2 Parameters
O2 Results
 Residuals

Reference Cylinders, Assigned Concentrations, and Calculated Offsets from Fit

(Position, Cylinder ID, SIO CO2 in ppm, SIO Delta-CO2, SIO CO2 sigma, GMD CO2 in ppm, GMD Delta-CO2, GMD CO2 sigma, CO2 n, d(O2/N2) in per meg, Delta-d(O2/N2), d(O2/N2) sigma, d(O2/N2) n, Plots)

1 ND12042 399.283 0.000 0.000 399.150 0.000 0.000 5 -384.25 2.28 1.38 5    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2
7 ND19515 450.346 0.000 0.000 451.248 0.000 0.000 5 -707.13 -1.57 0.51 5    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2
8 CC71581 388.340 0.000 0.000 388.560 0.000 0.000 5 -454.95 2.45 1.19 5    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2
9 ND19677 370.558 0.000 0.000 370.748 0.000 0.000 5 -256.57 -2.97 1.05 5    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2

Measured Cylinders and Calculated Concentrations

(Position, Cylinder ID, Plots)
(Day of Year and Day Fraction, SIO CO2 in ppm, SD CO2 (ppm), d(O2/N2) in per meg, SD d(O2/N2) (per meg), GMD CO2 in ppm, SD CO2 (ppm), Plots)

2 CC177837    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2    CO2 Fits 3   O2 Fits 3
205.593 359.113 0.020 -415.41 10.40 358.382 0.020
205.603 359.119 0.014 -406.72 85.06 358.389 0.014
205.681 359.100 0.012 -400.54 7.54 358.366 0.012
205.697 359.085 0.010 -399.53 11.58 358.353 0.010
205.775 359.039 0.012 -399.15 28.54 358.305 0.012
205.791 359.031 0.011 -403.31 6.25 358.298 0.011
205.869 359.052 0.010 -403.46 7.13 358.321 0.010
205.884 359.076 0.016 -403.59 6.67 358.347 0.016
205.962 359.041 0.013 -402.07 6.21 358.309 0.013

3 CC177841    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
205.608 360.536 0.009 -229.00 30.37 359.979 0.009
205.676 360.523 0.013 -238.15 14.19 359.965 0.013
205.702 360.501 0.010 -241.59 11.80 359.942 0.010
205.770 360.467 0.011 -246.95 32.10 359.908 0.011
205.796 360.459 0.012 -246.03 5.96 359.899 0.012
205.863 360.494 0.013 -247.21 7.62 359.940 0.013
205.889 360.507 0.013 -247.04 7.22 359.950 0.013
205.957 360.473 0.013 -248.88 7.31 359.915 0.013

6 CC178444    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
205.613 379.071 0.012 -406.34 16.20 379.419 0.012
205.671 379.080 0.017 -414.33 23.18 379.428 0.017
205.707 379.060 0.014 -405.57 8.28 379.407 0.014
205.764 379.079 0.012 -406.48 9.13 379.427 0.012
205.801 379.068 0.009 -404.83 6.63 379.416 0.009
205.858 379.107 0.009 -403.48 6.65 379.454 0.009
205.895 379.070 0.009 -407.91 6.12 379.418 0.009
205.952 379.087 0.015 -404.85 5.73 379.434 0.015

10 D88536    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
205.634 397.413 0.016 -606.66 11.21 397.347 0.016
205.650 397.420 0.016 -607.31 9.63 397.355 0.016
205.728 397.384 0.012 -608.30 9.47 397.319 0.012
205.744 397.423 0.013 -601.46 12.41 397.357 0.013
205.822 397.389 0.010 -607.28 7.13 397.325 0.010
205.837 397.404 0.013 -603.94 7.20 397.339 0.013
205.916 397.411 0.011 -603.33 8.29 397.346 0.011
205.931 397.420 0.009 -601.06 6.51 397.355 0.009

11 D88532    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
205.639 389.417 0.011 -638.90 10.44 389.609 0.011
205.645 389.422 0.013 -636.54 12.49 389.614 0.013
205.733 389.408 0.012 -638.39 7.22 389.600 0.012
205.738 389.421 0.010 -632.85 7.99 389.612 0.010
205.827 389.405 0.011 -632.86 6.78 389.597 0.011
205.832 389.432 0.010 -629.86 6.13 389.624 0.010
205.921 389.432 0.010 -630.84 7.31 389.623 0.010
205.926 389.436 0.010 -626.85 39.51 389.627 0.010
