UEA CRAM Lab O2 and CO2 calibration results
RUN = 130715a
PROCESSED: 16:18:39 Tue 1Aug2023

Notes
Logfile

Results

Using data from 196.577 to 196.902 (Day of Year and Day Fraction)
(Position, CylinderID, SIO_CO2, SIO_CO2_sigma, SIO_CO2_slope, GMD_CO2, GMD_CO2_sigma, GMD_CO2_slope, CO2_n, d(O2/N2), d(O2/N2)_sigma, d(O2/N2)_slope, d(O2/N2)_n)

2 CC177837 359.059 0.014 -0.006 358.325 0.015 0.011 7 -404.05 2.73 -6.89 7
3 CC177841 360.486 0.014 0.039 359.927 0.015 0.057 7 -247.36 2.53 -12.68 7
4 D88532 389.432 0.012 0.079 389.624 0.012 0.076 7 -625.45 2.78 -9.22 7
6 CC178444 379.068 0.012 0.091 379.416 0.012 0.090 7 -407.42 3.05 4.15 7
10 D88536 397.405 0.013 -0.048 397.340 0.012 -0.046 7 -599.87 0.76 0.12 7
WT D743660 408.362 0.019 -0.169 407.907 0.018 -0.163 63 -661.02 1.61 -11.52 63
Text File

Raw Data and Diagnostics Figures

CO2 Timeseries
 CO2 Averages for Unknowns
 CO2 Averages for Knowns
Jog Ave. Diagnostics 1
 Jog Ave. Diagnostics 2
 Jog Std. Dev. Diagnostics
Jog Slope Diagnostics
 Rollover Effect
 Flushing Effect
CO2 Parameters
 CO2 Results
 O2 Timeseries
O2 Averages for Unknowns
 O2 Averages for Knowns
 O2 Parameters
O2 Results
 Residuals

Reference Cylinders, Assigned Concentrations, and Calculated Offsets from Fit

(Position, Cylinder ID, SIO CO2 in ppm, SIO Delta-CO2, SIO CO2 sigma, GMD CO2 in ppm, GMD Delta-CO2, GMD CO2 sigma, CO2 n, d(O2/N2) in per meg, Delta-d(O2/N2), d(O2/N2) sigma, d(O2/N2) n, Plots)

1 ND12042 399.283 0.000 0.000 399.150 0.000 0.000 7 -384.25 2.59 3.07 7    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2
7 ND19515 450.346 0.000 0.000 451.248 0.000 0.000 7 -707.13 -1.12 0.71 7    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2
8 CC71581 388.340 0.000 0.000 388.560 0.000 0.000 7 -454.95 0.99 1.69 7    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2
9 ND19677 370.558 0.000 0.000 370.748 0.000 0.000 7 -256.57 -2.47 1.72 7    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2

Measured Cylinders and Calculated Concentrations

(Position, Cylinder ID, Plots)
(Day of Year and Day Fraction, SIO CO2 in ppm, SD CO2 (ppm), d(O2/N2) in per meg, SD d(O2/N2) (per meg), GMD CO2 in ppm, SD CO2 (ppm), Plots)

2 CC177837    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2    CO2 Fits 3   O2 Fits 3
196.526 359.099 0.013 -404.34 6.60 358.361 0.013
196.536 359.088 0.013 -400.54 6.71 358.349 0.013
196.614 359.065 0.016 -402.73 6.38 358.328 0.016
196.630 359.053 0.010 -403.79 7.81 358.317 0.010
196.708 359.036 0.013 -406.51 6.52 358.301 0.013
196.724 359.077 0.010 -401.00 5.66 358.345 0.010
196.802 359.065 0.015 -407.58 5.96 358.331 0.015
196.817 359.067 0.014 -400.73 7.98 358.338 0.014
196.895 359.048 0.011 -406.03 6.07 358.315 0.011

3 CC177841    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
196.541 360.501 0.009 -246.19 4.91 359.936 0.009
196.609 360.497 0.018 -246.57 7.20 359.936 0.018
196.635 360.471 0.010 -248.22 6.88 359.909 0.010
196.703 360.462 0.013 -246.12 6.90 359.902 0.013
196.729 360.492 0.013 -244.69 6.69 359.933 0.013
196.796 360.500 0.012 -245.58 6.17 359.942 0.012
196.823 360.494 0.009 -248.00 5.54 359.938 0.009
196.890 360.486 0.013 -252.34 6.00 359.928 0.013

4 D88532    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
196.546 389.403 0.014 -627.07 6.89 389.595 0.014
196.604 389.437 0.011 -620.86 6.05 389.628 0.011
196.640 389.410 0.013 -627.26 5.89 389.602 0.013
196.698 389.425 0.010 -626.64 7.62 389.617 0.010
196.734 389.430 0.009 -623.26 7.77 389.622 0.009
196.791 389.440 0.011 -629.41 5.72 389.631 0.011
196.828 389.439 0.010 -625.61 6.08 389.630 0.010
196.885 389.446 0.007 -625.07 5.49 389.637 0.007

6 CC178444    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
196.552 379.033 0.011 -409.87 6.56 379.381 0.011
196.599 379.059 0.012 -406.68 5.84 379.407 0.012
196.645 379.068 0.013 -404.77 6.95 379.415 0.013
196.692 379.054 0.013 -413.62 6.83 379.401 0.013
196.739 379.064 0.013 -406.61 7.25 379.412 0.013
196.786 379.075 0.014 -408.95 7.89 379.422 0.014
196.833 379.070 0.011 -405.13 5.75 379.417 0.011
196.880 379.090 0.012 -406.18 6.12 379.438 0.012

10 D88536    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
196.573 397.424 0.009 -598.30 6.06 397.358 0.009
196.578 397.430 0.008 -599.58 6.69 397.364 0.008
196.666 397.396 0.013 -599.56 6.53 397.332 0.013
196.671 397.395 0.011 -600.22 6.90 397.330 0.011
196.760 397.395 0.011 -600.98 5.29 397.330 0.011
196.765 397.411 0.009 -599.59 6.54 397.346 0.009
196.854 397.400 0.012 -600.51 6.28 397.335 0.012
196.859 397.407 0.012 -598.68 8.02 397.342 0.012
