UEA CRAM Lab O2 and CO2 calibration results
RUN = 130524a
PROCESSED: 11:28:15 Tue 1Aug2023

Notes
Logfile

Results

Using data from 144.692 to 144.801 (Day of Year and Day Fraction)
(Position, CylinderID, SIO_CO2, SIO_CO2_sigma, SIO_CO2_slope, GMD_CO2, GMD_CO2_sigma, GMD_CO2_slope, CO2_n, d(O2/N2), d(O2/N2)_sigma, d(O2/N2)_slope, d(O2/N2)_n)

2 CC177837 359.211 0.029 -0.476 358.470 0.026 -0.401 3 -411.37 2.23 -8.28 3
3 CC177841 360.616 0.037 -0.340 360.051 0.035 -0.315 3 -243.89 3.30 84.26 3
6 CC178444 379.073 0.051 0.366 379.422 0.051 0.367 3 -407.68 3.51 62.89 3
WT D88536 424.238 0.040 -0.379 423.488 0.039 -0.351 21 -694.04 3.75 103.26 21
Text File

Raw Data and Diagnostics Figures

CO2 Timeseries
 CO2 Averages for Unknowns
 CO2 Averages for Knowns
Jog Ave. Diagnostics 1
 Jog Ave. Diagnostics 2
 Jog Std. Dev. Diagnostics
Jog Slope Diagnostics
 Rollover Effect
 Flushing Effect
CO2 Parameters
 CO2 Results
 O2 Timeseries
O2 Averages for Unknowns
 O2 Averages for Knowns
 O2 Parameters
O2 Results
 Residuals

Reference Cylinders, Assigned Concentrations, and Calculated Offsets from Fit

(Position, Cylinder ID, SIO CO2 in ppm, SIO Delta-CO2, SIO CO2 sigma, GMD CO2 in ppm, GMD Delta-CO2, GMD CO2 sigma, CO2 n, d(O2/N2) in per meg, Delta-d(O2/N2), d(O2/N2) sigma, d(O2/N2) n, Plots)

1 ND12042 399.283 0.000 0.000 399.150 0.000 0.000 3 -384.25 6.97 1.04 3    CO2 Fits 1    O2 Fits 1
7 ND19515 450.346 0.000 0.000 451.248 0.000 0.000 3 -707.13 -1.83 0.52 3    CO2 Fits 1    O2 Fits 1
8 CC71581 388.340 0.000 0.000 388.560 0.000 0.000 3 -454.95 -3.87 1.42 2    CO2 Fits 1    O2 Fits 1
9 ND19677 370.558 0.000 0.000 370.748 0.000 0.000 3 -256.57 -7.36 2.88 3    CO2 Fits 1    O2 Fits 1

Measured Cylinders and Calculated Concentrations

(Position, Cylinder ID, Plots)
(Day of Year and Day Fraction, SIO CO2 in ppm, SD CO2 (ppm), d(O2/N2) in per meg, SD d(O2/N2) (per meg), GMD CO2 in ppm, SD CO2 (ppm), Plots)

2 CC177837    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
144.654 359.197 0.047 -376.17 9.20 358.445 0.047
144.664 359.239 0.056 -396.70 9.58 358.495 0.056
144.722 359.206 0.052 -413.03 9.81 358.463 0.052
144.737 359.242 0.061 -408.83 10.53 358.499 0.061
144.795 359.185 0.058 -412.25 8.24 358.448 0.058

3 CC177841    CO2 Fits 1   O2 Fits 1
144.669 360.601 0.055 -230.33 10.99 360.031 0.055
144.716 360.602 0.054 -247.46 7.36 360.037 0.054
144.742 360.658 0.052 -243.25 10.72 360.090 0.052
144.789 360.588 0.040 -240.97 9.72 360.025 0.040

6 CC178444    CO2 Fits 1   O2 Fits 1
144.674 379.066 0.055 -407.74 8.79 379.415 0.055
144.711 379.088 0.058 -411.50 10.49 379.437 0.058
144.748 379.016 0.039 -404.61 10.14 379.366 0.039
144.784 379.115 0.069 -406.91 9.92 379.463 0.069
