UEA CRAM Lab O2 and CO2 calibration results
RUN = 170810a
PROCESSED: 16:18:15 Mon 21Aug2023

Notes
Logfile

Results

Using data from 222.763 to 222.969 (Day of Year and Day Fraction)
(Position, CylinderID, SIO_CO2, SIO_CO2_sigma, SIO_CO2_slope, GMD_CO2, GMD_CO2_sigma, GMD_CO2_slope, CO2_n, d(O2/N2), d(O2/N2)_sigma, d(O2/N2)_slope, d(O2/N2)_n)

2 D88489 400.109 0.008 0.071 400.317 0.008 0.071 5 -462.41 1.02 -4.47 5
14 D88472 409.574 0.016 0.022 409.769 0.016 0.022 5 -1187.46 4.14 -11.37 5
15 D88474 409.338 0.007 -0.045 409.533 0.007 -0.045 5 -519.61 3.51 -17.85 5
WT D258964 397.601 0.003 0.005 397.812 0.003 0.005 40 -752.72 1.20 19.59 40
Text File

Raw Data and Diagnostics Figures

CO2 Timeseries
 CO2 Averages for Unknowns
 CO2 Averages for Knowns
Jog Ave. Diagnostics 1
 Jog Ave. Diagnostics 2
 Jog Std. Dev. Diagnostics
Jog Slope Diagnostics
 Rollover Effect
 Flushing Effect
CO2 Parameters
 CO2 Results
 O2 Timeseries
O2 Averages for Unknowns
 O2 Averages for Knowns
 O2 Parameters
O2 Results
 Residuals

Reference Cylinders, Assigned Concentrations, and Calculated Offsets from Fit

(Position, Cylinder ID, SIO CO2 in ppm, SIO Delta-CO2, SIO CO2 sigma, GMD CO2 in ppm, GMD Delta-CO2, GMD CO2 sigma, CO2 n, d(O2/N2) in per meg, Delta-d(O2/N2), d(O2/N2) sigma, d(O2/N2) n, Plots)

3 D073409 398.707 -0.003 0.002 398.918 -0.004 0.002 5 -651.78 0.30 0.45 5    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2
5 D089507 428.087 -0.004 0.003 428.275 -0.006 0.003 5 -559.23 -0.75 0.72 5    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2
9 D073419 440.065 0.001 0.001 440.275 0.002 0.001 5 -919.32 1.26 0.33 5    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2
12 D073418 413.092 0.006 0.004 413.280 0.008 0.004 5 -779.40 -1.83 0.50 5    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2
13 D801299 381.475 0.001 0.000 381.695 0.001 0.000 5 -477.75 0.83 0.67 5    CO2 Fits 1    O2 Fits 1    CO2 Fits 2   O2 Fits 2

Measured Cylinders and Calculated Concentrations

(Position, Cylinder ID, Plots)
(Day of Year and Day Fraction, SIO CO2 in ppm, SD CO2 (ppm), d(O2/N2) in per meg, SD d(O2/N2) (per meg), GMD CO2 in ppm, SD CO2 (ppm), Plots)

2 D88489    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
222.723 400.129 0.013 -459.58 2.13 400.337 0.013
222.801 400.100 0.013 -463.12 1.67 400.307 0.013
222.806 400.105 0.011 -460.96 2.01 400.313 0.011
222.884 400.108 0.016 -463.38 2.35 400.316 0.016
222.889 400.122 0.015 -461.74 2.13 400.330 0.015
222.967 400.111 0.012 -462.82 2.16 400.319 0.012

14 D88472    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
222.754 409.585 0.014 -1184.08 2.01 409.779 0.014
222.769 409.579 0.013 -1183.61 1.85 409.773 0.013
222.837 409.554 0.015 -1192.84 2.90 409.749 0.015
222.853 409.587 0.016 -1185.65 2.37 409.781 0.016
222.921 409.560 0.013 -1190.87 2.45 409.755 0.013
222.936 409.591 0.012 -1184.33 2.09 409.785 0.012

15 D88474    CO2 Fits 1   O2 Fits 1    CO2 Fits 2   O2 Fits 2
222.759 409.356 0.014 -518.52 2.03 409.550 0.014
222.764 409.340 0.016 -518.88 1.95 409.535 0.016
222.842 409.347 0.011 -514.80 1.92 409.541 0.011
222.848 409.335 0.010 -522.20 2.14 409.530 0.010
222.926 409.340 0.012 -518.40 1.84 409.535 0.012
222.931 409.328 0.012 -523.77 2.03 409.523 0.012
